Re: [Mk2] [Turbo] Oil Pressure/temp

Post by Ryan S »

Ah I see, ok this seems so much simpler now ha ha, ok, so anyone seen any decent cheap gauges with the appropriate senders ? Only 52mm as I want them on an a pillar pod:) oh, and thanks for everyones help:)
GTS GAV
Posts: 1092
Joined: Wed Nov 25, 2009 7:08 pm

Re: [Mk2] [Turbo] Oil Pressure/temp

Post by GTS GAV »

this is what i am fitting there good pieace of kit and include sensors :thumleft:

http://cgi.ebay.co.uk/Blue-Stepper-Moto ... 335cdc522a
stock isnt that soup or something.....?

tic tac 500bhp build thread
http://www.imoc.co.uk/forums/viewtopic. ... 57#1182357
Ryan S
IMOC Moderator
Posts: 10902
Joined: Sat Dec 10, 2005 1:32 pm
Location: Bonnie Dundee
Contact:

Re: [Mk2] [Turbo] Oil Pressure/temp

Post by Ryan S »

nice but a bit pricey, i like cheap ones lol!!!!
GTS GAV
Posts: 1092
Joined: Wed Nov 25, 2009 7:08 pm

Re: [Mk2] [Turbo] Oil Pressure/temp

Post by GTS GAV »

pricey are you mad thats cheap as your guna get buddy, you may get cheaper but i can guarantee it wont come with the sensor etc then when you have forked out for them it will work out the same if not more cash
stock isnt that soup or something.....?

tic tac 500bhp build thread
http://www.imoc.co.uk/forums/viewtopic. ... 57#1182357
GTS GAV
Posts: 1092
Joined: Wed Nov 25, 2009 7:08 pm

Re: [Mk2] [Turbo] Oil Pressure/temp

Post by GTS GAV »

i fitted mine tanite buddy and took loads of pics so you can copy :thumleft:

the stock sensor it the one with the yellow wire coming from it, disconect the plug and use a spanner to remove it from the head.








sensor out





with the braided line/fitting i posted there will be a little copper fitting use a bit of PTFE tape this can be found from any plumbing outlet, or b ang q etc, wrap a small amount around the thread and srew in the head as pictured






then fit the line to the fitting







aftermarket sensor in the side and stock in the centre of the fitting, remeber you may hav to exstend the yellow wire coming from the stock sensor this is easy enough though





they supply a fitting braket with the braided line so put it around the large nut and fix into place, plug the aftermarket sensor cable into the back of the gauge then power supply job done :thumleft:




stock isnt that soup or something.....?

tic tac 500bhp build thread
http://www.imoc.co.uk/forums/viewtopic. ... 57#1182357
Ryan S
IMOC Moderator
Posts: 10902
Joined: Sat Dec 10, 2005 1:32 pm
Location: Bonnie Dundee
Contact:

Re: [Mk2] [Turbo] Oil Pressure/temp

Post by Ryan S »

Ah nice, thanks a lot dude:):)
GTS GAV
Posts: 1092
Joined: Wed Nov 25, 2009 7:08 pm

Re: [Mk2] [Turbo] Oil Pressure/temp

Post by GTS GAV »

no problem buddy glad i could help :thumleft:

if you have any other querys just ask matey :thumleft:
stock isnt that soup or something.....?

tic tac 500bhp build thread
http://www.imoc.co.uk/forums/viewtopic. ... 57#1182357
Ryan S
IMOC Moderator
Posts: 10902
Joined: Sat Dec 10, 2005 1:32 pm
Location: Bonnie Dundee
Contact:

Re: [Mk2] [Turbo] Oil Pressure/temp

Post by Ryan S »

thread revival!!!!!!

can anyone tell me where the sender for the boost gauge is??? do i just use the stock one?????

coz i snapped it :( so the stock gauge doesn't work now, not that it's a problem as i have after market boost gauge :thumleft: :thumleft: :thumleft:
djpkins
Posts: 2326
Joined: Thu Apr 30, 2009 7:13 am
Location: essex

Re: [Mk2] [Turbo] Oil Pressure/temp

Post by djpkins »

The pressure sensor for the boost guage,oem, is next to the diagnostics plug...and is useless for your boost guage.

You should get everything you need to fit when you buy the guage...have you bought? if not then get it from r-speckers...I have their stepper peak/warning series in my car...accurate, look good, can have them lighting up red at night if you want and much less than defi etc, you want something that is accurate and reliable if your removing stock items.
toxo
IMOC Committee
Posts: 11345
Joined: Tue May 30, 2006 5:41 pm
Location: The Toast Aisle
Contact:

Re: [Mk2] [Turbo] Oil Pressure/temp

Post by toxo »

sheppy wrote:thread revival!!!!!!

can anyone tell me where the sender for the boost gauge is??? do i just use the stock one?????

coz i snapped it :( so the stock gauge doesn't work now, not that it's a problem as i have after market boost gauge :thumleft: :thumleft: :thumleft:


You need to fix that :) Rev1/2 the stock MAP sensor is used for fuel cut, so you won't have any at the moment and it's getting cold, so boost spikes are likely! As above, it's a black box on the rear bulkhead near the diagnostics box, it should have a silver label on it saying TURBO PRESSURE SENSOR and a small vac hose going into the bottom.
IMOC-UK - the only club to win 'Best Club Stand' at JAE more than once, and twice in a row!
Ryan S
IMOC Moderator
Posts: 10902
Joined: Sat Dec 10, 2005 1:32 pm
Location: Bonnie Dundee
Contact:

Re: [Mk2] [Turbo] Oil Pressure/temp

Post by Ryan S »

thanks for the help, i'm sure it's a wee blue plug a snapped, dunno if it's just the actual boost gauge i've broken or if it the sender or what??

i've not a bought a boost gauge yet(not a stepper one anyway), i'm using an after market mechanical one, but, i wanna change due to the accuracy of the steppers :)
djpkins
Posts: 2326
Joined: Thu Apr 30, 2009 7:13 am
Location: essex

Re: [Mk2] [Turbo] Oil Pressure/temp

Post by djpkins »


the map sensor is bottom left, next to the plenum chamber


here is another shot of one bottom left


this is my r-speckers stepper warn/peak series 60mm guages doing there natty start up sequence
Ryan S
IMOC Moderator
Posts: 10902
Joined: Sat Dec 10, 2005 1:32 pm
Location: Bonnie Dundee
Contact:

Re: [Mk2] [Turbo] Oil Pressure/temp

Post by Ryan S »

ah cool, na, it's not that i've broken then, it was when i was fittin(it was actually the foreman of arnold clark who's a friend of mine who was trying to help) my boost controller, wee plug, very hard to access, anyways, the boost gauge(stock one) stopped working after that :thumleft:
djpkins
Posts: 2326
Joined: Thu Apr 30, 2009 7:13 am
Location: essex

Re: [Mk2] [Turbo] Oil Pressure/temp

Post by djpkins »

Mine has never worked and has been unplummed and unplugged for 2 years..lol..think my Mines ecu removes fuel cut or raises it or whatever...fk fuel cut is for girls anyway...hahahaha..I'm sure that an after market fuel cut defenser wouldn't break the bank and is a good idea really...tbh I don't think I have ever hit fuel cut, and I do give it the beans...maybe I need one aswell...I could wear my nice flowery skirt when I fit it..lololol.
Where abouts was the little thing that you snapped sheppy?
Ryan S
IMOC Moderator
Posts: 10902
Joined: Sat Dec 10, 2005 1:32 pm
Location: Bonnie Dundee
Contact:

Re: [Mk2] [Turbo] Oil Pressure/temp

Post by Ryan S »

yeah mt fuel cut is raised to 17psi anyway via aftermarket defender :) the thing i snapped is near the VSV :lol:
